50.Electrical Symbols AutoCAD Blocks

p-Channel MOSFETs Symbol

The metal–oxide–semiconductor field-effect transistor (MOSFET, MOS-FET, or MOS FET) is a type of field-effect transistor (FET). It has an insulated gate, whose voltage determines the conductivity of the device. This ability to change conductivity with the amount of applied voltage can be used for amplifying or switching electronic signals. Although FET is sometimes used when referring to MOSFET devices, other types of field-effect transistors also exist.

n-Channel MOSFETs Symbol
The metal–oxide–semiconductor field-effect transistor (MOSFET, MOS-FET, or MOS FET) is a type of field-effect transistor (FET). It has an insulated gate, whose voltage determines the conductivity of the device. This ability to change conductivity with the amount of applied voltage can be used for amplifying or switching electronic signals. Although FET is sometimes used when referring to MOSFET devices, other types of field-effect transistors also exist.

Logic Gates Symbol
There are seven basic logic gates: AND, OR, XOR, NOT, NAND, NOR, and XNOR.

The AND gate is so named because, if 0 is called “false” and 1 is called “true,” the gate acts in the same way as the logical “and” operator. The following illustration and table show the circuit symbol and logic combinations for an AND gate. (In the symbol, the input terminals are at left and the output terminal is at right.) The output is “true” when both inputs are “true.” Otherwise, the output is “false.”

Integrated Circuits Symbol

Operational Amplifiers

Inductors symbols

I also suggest downloading Electric Symbols.

File format: .DWG
Size: 145KB
Source: dwgshare.com
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process

Electric Symbols
