21.Fire Extinguisher Cabinets Cad Blocks

Fire Extinguisher Cabinets Dry Chemical and Carbon Dioxide
1. Push To Open Lockable Device, Keyed Lock, Finished Chromed.
2. Safety Glass 5 Mm. Thick Door Panel.
3. surface Type Cabinet Made Of 1.6 Mm.(16 Gauge) Steel With Steel Trim & Doorframe, Door To Be Furnished With Continuous Steel Hing (brass Pin), With Push To Open Lockable Device, Keyed Alike, Cabinet Shall Be Cleaned & Coated With Phosphate Solution Prior To Being Finished With Baked On Red Painting (osha Red)
4. Continuous Steel Hinge With Brass Pin.
5. ABC Dry Chemical (ammonium Phosphate Base) Fire Extinguisher, 4.5 Kg.(10 Lb), Ul/fm Listed.

Download

File format: .DWG
Size: 105KB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
