255. CAD blocks of various types of seating furniture, including chairs, sofas, and stools
255. CAD blocks of various types of seating furniture, including chairs, sofas, and stools
CAD blocks of various types of seating furniture, including chairs, sofas, and stools, offer detailed representations of these items in both 2D and 3D views. These CAD blocks are invaluable resources for architects, designers, and drafters, enabling them to easily incorporate seating furniture into their designs with precision and accuracy.
Here are some common types of seating furniture represented in CAD blocks:
- Chairs: CAD blocks of chairs come in a wide range of styles, including dining chairs, lounge chairs, office chairs, and accent chairs. These blocks typically include details such as seat height, width, and depth, as well as backrest and armrest dimensions.
- Sofas: CAD blocks of sofas depict various configurations, such as loveseats, sectionals, and L-shaped sofas. They showcase the overall dimensions of the sofa, including its length, width, and height, as well as details such as cushion thickness and armrest style.
- Armchairs: CAD blocks of armchairs feature single-seat seating furniture with armrests on either side. These blocks provide detailed representations of the chair’s overall dimensions, as well as the shape and size of the armrests and backrest.
- Stools: CAD blocks of stools encompass a range of styles, including bar stools, counter stools, and footstools. They showcase the stool’s height, width, and depth, as well as any additional features such as footrests or swivel mechanisms.
These CAD blocks are typically available in standard file formats such as DWG (AutoCAD) or DXF, making them compatible with a wide range of design software. Designers can easily insert these blocks into their drawings and customize them to suit their specific project requirements, saving time and effort in the design process.
I also suggest downloading Furniture in Plan Cad Blocks.
- File format: .DWG
- Size: 1.29 MB
- Source: Collect
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
