16.Gate Valve Autocad Drawing Free Download

Gate valves are widely used in fluid control systems to control valve flow. General doors are designed to be fully open or closed. When the gate valve is fully opened, there is no obstruction in the flow path resulting in very low friction loss.

File format: .DWG
Size: 3.91MB
Source: dwgshare.com
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
