Inspection command in Autocad and the detailed instruction

Inspection command in Autocad and the detailed instruction

1. The way to call the command

Enter from keyboard Select from Menu Icon
DIMINSPECT Dimension\ Inspection

2. Meaning of the command

This command is usually to add or delete the additional information for dimension line.

The additional information
The additional information

3. Diagram for carrying out

4. Explain the dialog box.

After calling the command, Inspection Dimension dialog box appears:

Select dimensions: Select the dimension lines (Picture X – 159).

Shape: Create the border around the additional information for dimension line.

Round: Create the round border.
Angular: Create the angular border
None: Do not create the border

Delete the additional information for dimension line. This node only appears when you select the dimension line to delete the information then call the command.

Label/Inspection rate: Add necessary information labels.

Good luck!

Thanks for reading!!!
