Lintype command in AutoCAD (LT command in CAD): Enter the linetypes in drawing. Below is the way to use LT command in CAD:

  • Command: Linetype
  • Menu:Format \ Linetype
  • Shortcut command : LT

Linetype, color and the width of drawing stroke can be assigned to layers or objects. Generally, when starting the drawing, there is only linetype “Continuous” on dialog box. To enter linetype, we use Linetype command or go to menu Format\ LineType… The dialog box Linetype Manager appears, and choose key Load like while creating layers, we assign linetype for any layer.

Good luck!

Thanks for reading!!!
