384. Download CAD Design Drawings for a 2-Story House with Dimensions 11.5m x 13.7m

The CAD drawings of this House include the following functional floor plans:

• 1st floor: Garage, 1 living room, 1 kitchen-dining room, and a wet yard
• 2nd floor: 3 bedrooms and 1 family room

This drawing includes the following plans: floor plan, elevation, and section of the building.
Feel free to view and download the entire CAD file of this townhouse for reference.
Additionally, you can download more house design drawings here

• File format: .DWG
• Size: 914 KB
• Source: Collect
• AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
