128. Free CAD Drawing Modern Dining Table Design

This free CAD drawing provides detailed plans for a modern dining table design. The set includes a Plan view, a Front Elevation, and a Side Elevation, all drawn to Scale 1:10. The drawing meticulously details the table’s dimensions, including overall length (1800), width (800), and height (750). Material specifications are noted, such as a white stone tabletop and a glossy painted MDF wood base. The distinct multi-legged base design is clearly illustrated in the plan view. These CAD drawings offer essential technical information for interior designers and furniture makers. They provide precise data needed for fabrication and help visualize the modern aesthetic.

Download this Drawing Modern Dining Table for free

I also suggest downloading Dining Room Details CAD Files

File format: .DWG
Size: 114 KB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
