640. Free DWG CAD Drawings of Double Staircase Atrium Elevations and Sections

This set of CAD drawings showcases detailed double staircase atrium elevations and sections. Key components include:
• Atrium Grid Plan: Dimensioned grid layout for spatial reference.
• Elevation View: Side view illustrating height and stair placement.
• Sectional Details: Cross-section highlighting structural elements like RCC columns and circular pipes.
• Material Specifications: Includes 75mm thick brick wall and RCC structures.
• Technical Annotations: Notations for pipe diameters and angular connectors.

These drawings are essential for architects and engineers involved in atrium design and construction, providing precise references for planning and execution.

I also recommend downloading the Cad Details CAD drawings for your project reference.

File format: .DWG
Size: 130 KB
Source: DWGshare
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
