133. Free CAD Drawing Modern Dining Table Design
Advertisements
This CAD drawing sheet provides highly detailed technical specifications for a modern dining table and chair set. The drawing is meticulously prepared for fabrication and features multiple coordinated views for both furniture pieces.
For the dining table, the sheet includes:
- Front Elevation (MẶT ĐỨNG): Illustrates the front profile of the table with its sleek design, tapered legs, and precise overall dimensions.
- Side Elevation (MẶT BÊN): Shows the side profile of the table, detailing its depth and height.
- Plan View (MẶT BẰNG): A top-down view of the rectangular tabletop, providing its full length and width.
For the dining chair (GHẾ), a detailed side elevation view is provided, showcasing its ergonomic form, seat height, backrest design, and overall dimensions.
133. Free CAD Drawing Modern Dining Table Design
I also suggest downloading Dining Room Details CAD Files
- File format: .DWG
- Size: 117 KB
- Source: Collect
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
