155. Download detailed CAD drawings of various types of staircases

Straight Staircase: This is the simplest type, characterized by a straight flight of steps from one floor to another without any turns or landings. It’s commonly found in small residences due to its simplicity and space efficiency.
L-Shaped Staircase: This staircase consists of two straight flights of stairs connected by a landing that turns 90 degrees. It’s suitable for homes with limited space and provides a more visually appealing design than a straight staircase.
U-Shaped Staircase: Similar to the L-shaped staircase, but with an additional landing at the bottom or top that reverses the direction of the stairs, forming a U-shape. It’s often used in larger homes and provides a more grand and spacious feel.
Spiral Staircase: This staircase features steps that wind around a central pole or axis, forming a spiral shape. It’s a space-saving option and adds an elegant and distinctive element to the home’s design. However, it may not be suitable for all users due to its narrower steps and tighter turns.
Curved Staircase: These staircases have steps that follow a curved or elliptical shape, creating a graceful and flowing design. They are often custom-made and can be a focal point of luxury homes or grand entrances due to their aesthetic appeal and architectural complexity.
Floating Staircase: Also known as cantilevered stairs, these staircases give the impression of floating as they lack visible support underneath the treads. They create a modern and minimalist look, perfect for contemporary-style homes, and allow for more light and openness in the space beneath the stairs.
Split Staircase: In this design, the staircase splits into two separate flights that go in opposite directions, usually at a landing in the middle. It provides a grand entrance and adds architectural interest to the home’s interior.

Each type of staircase offers its own unique benefits in terms of aesthetics, space utilization, and suitability for different architectural styles and preferences.

File format: .DWG
Size: 0.82 MB
Source: dwgshare.com
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
