183. Free Curved Ceiling CAD Section & Lighting Details

This detailed technical CAD drawing provides a comprehensive section view of a modern decorative ceiling design featuring a curved transition and integrated lighting. The drawing illustrates the layered construction, starting with the suspension system utilizing φ8 hot-dip galvanized fully threaded rods. It details the framing structure built with C50X20 light steel keels at specified spacing. The ceiling surface is formed using layers of 9.5mm paper-faced gypsum board and 12mm thick magnesium crystal board, carefully shaped to create the curved profile with indicated radii (e.g., R200). A recess is detailed for a recessed LED light strip. The drawing also specifies finishes such as inorganic paint and includes edge trim details. Precise dimensions, thicknesses, and spacing are provided throughout the section. An accompanying photographic rendering visualizes the finished aesthetic. This CAD drawing is an invaluable resource for architects, interior designers, and contractors requiring detailed construction methods, material specifications, and dimensions for fabricating complex curved and illuminated ceiling elements.

You can also find a wider selection of free Cad Blocks and DWG models available for download here: Free CAD Blocks download

• File format: .DWG
• Size: 59 KB
• Source: Collect
• AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
