4.Ball Valve AutoCAD Blocks
The ball valve is equipped with a spherical closure that can control the flow of air. The sphere has a port, also known as bore through the center. When the valve is in a boring position, it is in line with the pipe being open and the fluid can flow.
- File format: .DWG
- Size: 11.3MB
- Source: dwgshare.com
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
