476. Download CAD Design Drawings for a 3-Story House with Dimensions 4.3m x 16.4m

476. Download CAD Design Drawings for a 3-Story House with Dimensions 4.3m x 16.4m

This CAD drawing set presents the design proposal for a three-storey townhouse with overall dimensions of approximately 4.3 m × 16.4 m. This type of house is quite common in dense urban areas where the plot width is limited but the depth is relatively long. Looking through the drawings, it is clear that the designer tried to make the most of the available space while still maintaining a reasonable level of ventilation and natural light.

• The ground floor is organized in a fairly straightforward way. The front area is arranged as a small commercial or retail space, which could be used for business activities or product display. Because the space stretches along the length of the house, it feels more open than the actual width might suggest. Toward the back, a restroom and a few service areas are placed so that the main commercial space at the front remains uncluttered and functional.
• Moving up to the second floor, the layout shifts toward family living. The living room is located at the front, connected to the kitchen and dining area toward the back of the house. This arrangement is commonly seen in townhouse designs because it allows daily activities to flow naturally between spaces. The staircase sits roughly in the middle of the house, acting both as vertical circulation and as a subtle divider between different functional areas.
• The third floor is mainly dedicated to sleeping spaces. Bedrooms are arranged on either side of the staircase, including a larger master bedroom. Some rooms have windows facing the front or rear, allowing natural light and ventilation to enter the house. In narrow townhouses like this, thoughtful placement of windows is especially important to avoid a closed or stuffy interior environment.
• The top level is designed as a more flexible area. It can function as a worship room, laundry space, or an open terrace for drying clothes and placing plants. Because this level usually requires fewer partitions, it tends to feel more open and airy compared to the floors below.

Besides the floor plans, the drawing package also includes elevations, sections, and construction details, which help readers better understand the architectural form of the building. The elevation drawings show a relatively simple façade, relying on window proportions and vertical wall elements to create visual interest. The sectional drawings clarify floor heights, slab structures, and the position of the staircase throughout the building.

Overall, this is a fairly complete drawing set for a medium-scale townhouse. For designers, architects, or homeowners looking for ideas, the project offers a practical example of how living spaces can be organized effectively within a narrow urban plot.

I also recommend downloading other Houses CAD drawings for your project reference.

• File format: .DWG
• Size: 3.65 MB
• Source: DWGshare
• AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process

DOWNLOAD
