Stadium section Details AutoCAD File DWG
Advertisements
This CAD drawing presents the detailed sectional design of a modern stadium.
It includes:
- Steel truss roof structure with sloping beams supporting the grandstand canopy.
- Multi-tiered spectator stands, carefully detailed with seat rows and level dimensions.
- Functional spaces under the stands, such as technical rooms, corridors, and service areas.
- Structural elements including columns, beams, foundations, and reinforcement details for safety and stability.
- Elevation markers and technical notes that provide precise guidance for construction and implementation.
This AutoCAD drawing is an essential reference for architects, engineers, and contractors in the planning and construction of stadium projects.
Stadium section Details AutoCAD File DWG
I also suggest downloading Sports And Games.
- File format: .DWG
- Size: 864 KB
- Source: dwgshare.com
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
