17. Free CAD Drawing Modern Sectional Sofa

This collection of CAD drawings provides detailed plans for a modern sectional sofa. Key components include: Sofa Dimensions: Total length of 2350mm with a depth of 1750mm. Materials: Upholstered in fabric, designed for comfort and durability. Frame and Legs: Sturdy design with inox steel legs. Views Included: Plan View: Top-down layout showing overall dimensions and configuration. Elevation Views: Side and front profiles for detailed height and depth insights. 3D Rendering: Visual representation showcasing the sofa in a realistic setting. This set is of great professional value for interior designers, architects, and furniture manufacturers, facilitating effective planning and execution in both residential and commercial projects. Download now to enhance your design and planning toolkit.

I also suggest downloading Furniture Details CAD Files

File format: .DWG
Size: 2 MB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
