18. Free CAD Drawing Modern Sectional Sofa

This set of CAD drawings showcases a modern sectional sofa design. It includes detailed views of various components, providing essential details for understanding and utilizing the design. Key features include:

Overall Dimensions: Length 3000 mm, Depth 1878 mm, Height 840 mm.
Material Specifications: Premium padding, upholstered in high-quality fabric.
Construction Details: Inox base for durability and style.
Views Included:

– Elevation: Front and side perspectives highlighting the sofa’s contours.
– Plan View: Top-down view showing the seating arrangement and sectional layout.

These detailed drawings are tailored for architects, interior designers, and manufacturers, offering practical insights for planning and construction. The provided dimensions and material specifications make it ideal for precise manufacturing and custom installations. Download these free drawings to enhance your design library and streamline your creative projects.

I also recommend downloading other Furniture CAD drawings for your project reference.

File format: .DWG
Size: 128 KB
Source: DWGshare
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
