180. Download CAD drawings for technical design and construction of gate and fence for townhouse

The CAD drawing in the image provides a detailed design of the gate and fence for a residential project. Here is a detailed description:

Gate and Fence Elevation View:
- Main Gate: Designed with four panels featuring a decorative circular pattern in the center, possibly a traditional motif.
- Side Gate: Smaller in size, featuring two simpler panels compared to the main gate.
- Fence Structure: Consists of main pillars and a metal or alloy fence system.
- Lighting System: Includes top-mounted lights on both gate pillars to enhance aesthetics.
- Gate Roof: A tiled roof style, adding elegance and fitting traditional architectural elements.
Gate and Fence Plan View:
- Displays the overall layout of the main gate, side gate, courtyard, and landscape area.
- Detailed dimensions for each section, ensuring precision in construction.
- Decorative elements such as greenery and a fountain add visual appeal to the landscape.

The drawing includes precise dimensions, material specifications, and structural details, making it suitable for technical design and construction.

You can also find a wider selection of free Cad Blocks and DWG models available for download here: Free CAD Blocks download

File format: .DWG
Size: 380 KB
Source: dwgshare.com
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
