184. Free download CAD section of gypsum ceiling with classic European molding
This CAD drawing presents two detailed cross-sections of a gypsum ceiling design with classic European-style molding. It illustrates the construction and decorative integration of the ceiling system using LED lighting and molding features:
Section 1-1:
- Shows a layered ceiling design with dropped gypsum panels supported by concealed frames.
- Decorative crown molding (phào trần and phào góc trần) enhances the ceiling perimeter.
- Includes an LED cove lighting strip that highlights the molding contours.
- The framing system is anchored to the wall using a steel furring channel.
Section 2-2:
- Similar construction as section 1-1 but includes a curtain recess (khe rèm) at the right edge.
- The LED strip remains hidden behind molding for soft ambient lighting.
- All components such as frame levels, gypsum boards, and lighting are dimensioned precisely (e.g. 200 mm drop, 800 mm spacing).
You can also find a wider selection of free Cad Blocks and DWG models available for download here: Free CAD Blocks download
- File format: .DWG
- Size: 259 KB
- Source: Collect
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
