298. Free Download detailed CAD drawings of townhouse stairs
Looking for a free download of a CAD file for a technical staircase drawing? This free CAD drawing provides comprehensive technical details for a staircase and elevator system in a townhouse. The CAD file includes four main views at 1:50 scale, offering vital construction information.
You get plan views for the Basement-Ground and 5th Floor-Terrace levels showing staircase layouts and elevator positions. Detailed sectional elevations (Section A-A, B-B) illustrate precise technical specifications, including step dimensions (rise/run), landing construction, and handrail details. This CAD drawing of the staircase serves as an essential resource for architects and builders needing accurate staircase technical drawing information. Download this free CAD file today to streamline your design and construction planning with detailed staircase CAD data.
You can also find a wider selection of free Cad Blocks and DWG models available for download here: Free CAD Blocks download
- File format: .DWG
- Size: 141 KB
- Source: dwgshare.com
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
If you find our work useful, your support would mean a lot and help us grow even better.DONATE
