325. Free Download Multi-Level Staircase CAD Drawing – Section and Floor Plans
Advertisements
This detailed CAD drawing showcases a multi-level staircase design, including floor plans from ground to first floor, first to second floor, and second floor to terrace. It also features a full vertical section view with accurate floor heights, riser dimensions, landing lengths, and technical details. The design includes a central elevator shaft, surrounded by stair flights, making it suitable for townhouses, villas, or commercial buildings.
All dimensions are clearly labeled at a 1:50 scale, making the drawing easy to understand and apply for architects, civil engineers, or students. This professional technical drawing is well-organized and ideal for construction and design reference.
325. Free Download Multi-Level Staircase CAD Drawing – Section and Floor Plans
Click here to free download detailed staircase CAD drawings, with hundreds of diverse models for any project.
- File format: .DWG
- Size: 278 KB
- Source: dwgshare.com
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
