475. Download CAD Design Drawings for a 3-Story House with Dimensions 7.4m x 17.2m

Looking at this CAD drawing set, it is clear that the design represents a three-storey townhouse built on a plot measuring approximately 7.4m by 17.2m. This type of house is very common in many urban neighborhoods today, where land is limited but homeowners still need comfortable living space for the entire family. One of the first things that stands out is how efficiently the floor plan uses the long and narrow shape of the site.

The ground floor follows a layout that is quite familiar in townhouse design. At the front, there is a garage combined with a small setback area that creates a buffer between the house and the street. Moving inside, the living room connects directly to the kitchen and dining area. This open arrangement helps the space feel larger while also allowing daily family activities to flow more naturally. The staircase sits roughly in the middle of the house, acting as the main circulation spine while subtly separating the functional zones.

The second floor is mainly reserved for private living spaces. Bedrooms are arranged along a corridor, and each room includes windows or a balcony to bring in natural light and ventilation. This detail may seem simple, but it is extremely important in narrow urban houses where airflow and daylight can easily become limited.

On the top floor, the design introduces quieter and more personal spaces such as a worship room, a small reading area, or a family lounge. There is also a laundry terrace and rooftop space that can be used for plants or casual outdoor relaxation.

Architecturally, the façade reflects a modern style with clean geometric volumes. Light-colored walls are combined with darker materials to create visual contrast, while large windows and balconies help keep the elevation open and balanced.

Overall, this drawing set provides a practical reference for anyone looking for ideas when designing a three-storey townhouse on a similar lot size.

I also recommend downloading other Houses CAD drawings for your project reference.

File format: .DWG
Size: 1 MB
Source: DWGshare
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
