540. Free Download of Detailed CAD Drawing of Ceiling for Residential Projects

This CAD section drawing illustrates a suspended ceiling system with integrated lighting, ventilation, and layered materials used for finishing. It appears to be a typical section for a residential or commercial interior ceiling system, especially for areas with technical installations like air conditioning or mechanical ducts.

Ceiling Finishing Layers

• 12mm Crystallized Magnesium Board (Magie Board):
  Used as the primary ceiling board for durability and fire resistance.

• 9.5mm Gypsum Board (Paper-faced):
  Attached below the magnesium board to provide a smooth and paintable finish surface.

• Recessed LED Light Strip:
  Installed within the ceiling cavity for ambient lighting.

  Advertisements

• Finish Paint:
  Labeled “PT-01” – refers to a specific paint finish code.
  Non-gloss paint finish.

You can also find a wider selection of free Cad Blocks and DWG models available for download here: Free CAD Blocks download

• File format: .DWG
• Size: 67.5 KB
• Source: Collect
• AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
