56. Free Download CAD Drawing of Second Floor Plan for School Building with Classrooms and Restroom Layout
Advertisements
Looking at this second-floor plan, the layout feels familiar for a mid-scale school building, yet it is handled in a clean and practical way. A main circulation corridor runs across the center, acting as the primary spine that distributes access to classrooms on both sides.
The classrooms are arranged in repetitive modules with similar sizes, making it easier to standardize furniture and manage daily operations. Between classroom clusters, small rooms labeled “storage” are inserted, likely used for equipment or teaching materials.
The restroom area is grouped to one side, separated from the main learning spaces but still within a convenient distance. The staircase is positioned at the end of the building, directly connected to the corridor, ensuring a clear and efficient circulation flow.
Overall, the layout is not overly complex, but it is well-organized and practical enough for real-world construction.
56. Free Download CAD Drawing of Second Floor Plan for School Building with Classrooms and Restroom Layout
- File format: .DWG
- Size: 113 KB
- Source: DWGshare
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
Above is the CAD floor plan drawing that you can download for free as a reference. To obtain the complete concept design package, please download it using the link provided below.
The main categories included in this CAD drawing set are:
- Floor Plan Drawings
- Elevation Drawings
- Section Drawings
