57. Cad Drawings Of Ceiling Detail For Download

57. Cad Drawings Of Ceiling Detail For Download
57. Cad Drawings Of Ceiling Detail For Download
57. Cad Drawings Of Ceiling Detail For Download

57. Cad Drawings Of Ceiling Detail For Download

Description:
This technical design drawing depicts the ceiling plan for the specified house. The ceiling design is aimed at providing both aesthetic appeal and functional utility.

Ceiling Material:
The ceiling material specified in this drawing is gypsum board, which is a common material known for its ease of installation and versatility in design.

Ceiling Structure:
The ceiling is supported by wooden joists spaced at regular intervals. The joists are securely attached to the main structural framework of the house. The ceiling height is standard, providing sufficient headroom while maintaining efficient use of space.

Ceiling Features:

Recessed Lighting: The drawing indicates the placement of recessed LED light fixtures strategically distributed across the ceiling. These fixtures provide ample illumination while contributing to a modern and minimalist aesthetic.
Cornice Detail: A decorative cornice detail is incorporated along the perimeter of the ceiling, adding a touch of elegance to the space.
Ventilation Ducts: The drawing also includes provisions for ventilation ducts to ensure proper air circulation within the house. These ducts are integrated seamlessly into the ceiling design to maintain a clean and uncluttered appearance.
Finishing:
The gypsum board ceiling is intended to be finished with a smooth surface, ready for painting. The choice of paint color is left to the discretion of the homeowner or as specified by the interior designer.

Overall, this technical design drawing provides a comprehensive overview of the proposed ceiling design for the specified house, combining functionality with aesthetics to create a comfortable and visually pleasing living space.

Cad Drawings Of Ceiling Detail in 2D DWG Drawing. I also suggest downloading Autocad Ceiling.

  • File format: .DWG
  • Size: 391 KB
  • Source: dwgshare.com
  • AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
