636. Download Free DWG AutoCAD Drawing of Bridge Vertical Profile and Sections

The CAD drawing above illustrates a detailed slab reinforcement layout plan for a building with a distinctive structure, consisting of two rotated square blocks on both sides and a central slab area. Different line colors are used to distinguish elements such as beams, columns, slabs, and reinforcement positions. Horizontal, vertical, and diagonal lines are clearly shown to indicate spacing, direction, and reinforcement dimensions within each slab section. At the center, there is a large square area, possibly a skylight or atrium, reinforced with parallel steel layers. The left and right blocks feature more complex structures, with diagonal beams and dense reinforcement arrangements to enhance load-bearing capacity. This drawing serves as an essential technical document, supporting construction, supervision, and quality control of the project.

You can also download the CAD Structure Details library here.

File format: .DWG
Size: 411 KB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
