69. Free Download Bed CAD Shop Drawing

This CAD drawing illustrates the detailed structure of a modern bed frame with an integrated storage box and drawers underneath. The drawing includes:

Front and Side Views: Shows the bed frame made from An Cuong MFC board, featuring a flat headboard and a body divided into equal compartments. The overall dimensions are 2046 mm in length and 1392 mm in width. Materials are clearly noted, including white-painted MDF edges.
Top View: Displays the mattress and pillows arranged to scale, providing a clear view of the bed layout within an interior space.
Detailed Side Elevation & Section 1-1: Highlights the drawer system and internal bed structure, including storage compartments, hinges, and precise drawer measurements.
Overall Section View: Presents a cross-sectional cut of the bed, revealing internal framing, drilled holes, and under-bed cabinet construction.

This drawing is ideal for real-world manufacturing, on-site installation, and technical presentations in bedroom interior design.

Perfect for luxury or neoclassical bedroom interiors.

I also suggest downloading Bedroom Details CAD Files

File format: .DWG
Size: 160 KB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
