12. Free CAD Drawing Modern Sectional Sofa

This free CAD drawing provides detailed information about two different modern sofa models. The drawing is presented as a collage with two separate parts:

1. Large Sofa Detail Set:

• Includes Elevation views from two directions and a Plan view of a long, multi-seat sofa.
• The drawings clearly show overall dimensions (e.g., length 2880, height 800, depth 850), seat height and depth dimensions, and details regarding the seat and back cushions.
• There is a note on the upholstery material (wood frame upholstered in fabric similar to the perspective image) and the scale (Scale 1:10).
• A small perspective image is included to help visualize the style.

2. Small Sofa and Ottoman Detail Set:

• Includes Elevation views and a Plan view of a smaller sofa (or large armchair) and an accompanying square ottoman.
• The drawings provide full dimensions for both the sofa (e.g., width 800, height 650, depth 800) and the ottoman (e.g., 800×800 square, height 430).
• There is a note on the upholstery material (gray felt fabric upholstered sofa) and the scale (Scale 1:10).
• A small perspective image is also included showing both the sofa and ottoman in a space.

Both detail sets include a note about checking dimensions before construction. This material is very valuable for interior design, sofa selection, and fabrication, providing necessary technical information along with visual references.

I also suggest downloading Living room Details CAD Files

• File format: .DWG
• Size: 4.89 MB
• Source: Collect
• AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
