386. Free download of CAD technical drawings for the construction of bathrooms in townhouses

Layout plans showing the arrangement of fixtures (toilet, sink, shower, etc.)
Floor tiling plans, specifying tile materials and dimensions
Ceiling plans, indicating paint layers and lighting placement
Section views, detailing elevation and technical construction per floor
Legend and notes, listing materials and technical symbols used

This drawing is ideal for architects, engineers, and builders working on residential housing projects, especially urban townhouses.

Click here to view and download free CAD drawings of detailed bathroom designs

File format: .DWG
Size: 2.98 MB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
