72. Free Download Bed CAD Shop Drawing

Advertisements

This CAD drawing provides a detailed description of a bed, including three main views. The “Elevation View” shows the front of the bed with overall length and height dimensions, along with the material note “MDF wood with a specified paint finish.” The “Floor Plan” presents the overall length and width dimensions of the bed, as well as the position of the pillows and blanket. The “Side Elevation” and “Side View” provide details on the side of the bed, including the useful drawers. Finally, the “Section View” clarifies the internal structure and dimensional details of the components. This drawing is very useful for carpenters and manufacturers to build the bed exactly as designed.

I also suggest downloading Bedroom Details CAD Files

File format: .DWG
Size: 139 KB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process

💡Remark: You’re welcome to contribute resources to DWGshare.com by sending us your PDF, DWG, or ZIP files via email at dwgshare.us@gmail.com. Thank you — we truly hope that each of your contributions will help build a stronger and more connected CAD community. If you find our work useful, your support would mean a lot and help us grow even better.DONATE
