315. Download free CAD structural drawings for a 9.7m x 16.8m reinforced concrete townhouse construction

Looking for high-quality CAD structural drawings for a compact reinforced concrete townhouse? This free download provides detailed AutoCAD files designed for a 9.7m x 16.8m modern townhouse construction, featuring essential structural elements.

Included in the CAD Drawings:

✅ Foundation Plan – Detailed layout of footings, slab, and reinforcement.
✅ Column and Beam Layouts – Accurate positioning of vertical and horizontal structural elements.
✅ Floor Slab Reinforcement – Complete steel reinforcement detailing for each floor.
✅ Roof Structure – Design specifications for concrete or lightweight roofing systems.
✅ Sections and Elevations – Clear cross-sections and elevation views for construction clarity.

These DWG files are ideal for architects, structural engineers, and builders looking for reliable townhouse construction drawings. Download now and streamline your project!

Download more free CAD design drawings for reinforced concrete townhouse structures here

• File format: .DWG
• Size: 2.1 MB
• Source: Collect
• AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
