95. CAD Construction Method for Bored Pile with Dynamic Crane Block

This CAD drawing illustrates the construction method of bored piles using a crawler crane and concrete mixer truck.
It shows two main stages: lowering the steel cage and casing pipe, followed by concrete placement using a tremie pipe.

The highlight of this drawing is the crawler crane designed as a dynamic block, which allows users to adjust boom height, reach angle, and configuration flexibly to simulate different working conditions.

Key components include the crawler crane, concrete mixer truck, casing pipe, pile reinforcement, and ground level markers.
This drawing is ideal for foundation engineers preparing construction method statements or technical presentations.

I also recommend downloading other Construction methods CAD drawings for your project reference.

File format: .DWG
Size: 842 KB
Source: DWGshare
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
