WE command in AutoCAD- Wedge command – Create the wedge solid

1. The way to call WE command in AutoCAD.

Scroll down menu	Screen menu	Type command	Tool bar
Draw » Modeling » Wedge	Draw2 » Solids » Wedge	We, Wedge	Modeling

Wedge command is to create the wedge solid model. The wedge is 3D solid with 5 surfaces, equals a half of the box shape with the same three-dimensional size.

Wedge

Specify first corner or [CEnter]: Specify a point as the first corner of the wedge.
Specify corner or [Cube/Length]: Enter another corner of the wedge or use an option.

2. Create the wedge – Define two vertexes of the opposite corner of the wedge

Specify first corner or [CEnter]: – Select P1 belonging to XY plane as the vertex of the first corner of the wedge.

Specify other corner or [Cube/Length]: @180,150,100 – Enter the vertex of other corner of rectangular box containing the wedge.

3. Create the wedge – Define a corner vertex, the opposite top of the bottom and the height

Specify first corner or [CEnter]: – Select P1 belonging to XY plane as the vertex of the first corner of the wedge.
Specify other corner or [Cube/Length]: @180, 150- Enter the vertex of opposite corner of the wedge bottom (P2).
Specify height or [2Point]: 100 – Enter the height of the wedge.

WE command in AutoCAD- Wedge command – Create the wedge solid

4. Create the wedge – Define the dimension of length, width, height

Specify first corner or [CEnter]: – Select P1 belonging to XY plane as the vertex of the first corner of the wedge.
Specify other corner or [Cube/Length]: L
Specify length: 180 8 – Enter length following to X axis.
Specify width: 140 8 – Enter width following to Y axis
Specify height: 100 8 – Enter height following to Z axis

5. Create the wedge – Define the vertex and the same size of 3 directions (Cube)

Specify first corner or [CEnter]: – Select P1 belonging to XY plane as the vertex of the first corner of the wedge.
Specify corner or [Cube/Length]: C
Specify length: 140 Enter length of the wedge edge

6. Create the wedge – Define the center and the coordinates of a corner vertex

Specify first corner or [CEnter]: C
Specify center: – Select O point as the center of the wedge.
Specify corner or [Cube/Length]: @80,85,70 – Enter the coordinates of a corner of the wedge in comparison with O center.
7. Create the wedge – Define the center, the coordinates of a vertex and height of the wedge.

Specify first corner or [CEnter]: C
Specify center: – Select O point as the center of the wedge.
Specify corner or [Cube/Length]: @80,85 – Enter the coordinates of a vertex of the rectangle in comparison with O center (The rectangle is in parallel and has the same dimension with the wedge bottom).
Specify height or [2Point]: 140 – Enter the height of the wedge.
2Point option is used to define the height of the wedge by distance of 2 selected points on screen.
