304. CAD design drawings for a 3-story townhouse with dimensions of 7.7m x 12m

The functional layout of this 3-storey house design is as follows:

• First floor: A garage, a living room, and a family room
• Mezzanine floor plan: One office
• Second floor plan: Includes 2 large bedrooms, a family room, and 2 private bathrooms
• Third floor plan: Includes 2 large bedrooms and 1 shared bathroom

This drawing includes the following plans: floor plan, elevation, and section of the building.
Feel free to view and download the entire CAD file of this townhouse for reference.
Additionally, you can download more house design drawings here

• File format: .DWG
• Size: 1.41 MB
• Source: Collect
• AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
