620. Scaffolding System Design for Circular Columns – Free CAD Template

This CAD drawing provides a collection of technical details for a specialized scaffolding system, designed for the construction of circular columns. The drawing presents typical configurations for columns of different diameters (e.g., Ø800, Ø1000), with each configuration including a full set of 2D views: a side elevation, a plan view, and a front elevation.

This scaffolding system is primarily designed to support formwork during the concrete pouring process for columns. The structure consists of vertical posts, horizontal ledgers, and a safe access platform at the top. An important detail is the lifting hook shown at the peak, indicating this is a system that can be pre-assembled and hoisted into position on-site.

With clear dimensions and construction details, this is a valuable technical reference, helping engineers and construction teams deploy the scaffolding system accurately and safely.

You can also download the CAD Structure Details library here.

File format: .DWG
Size: 2.4 MB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
