355. CAD design drawings for a 6-story townhouse with dimensions of 4m x 7m

The CAD drawings of this townhouse include the following functional floor plans:

First Floor: Garage and store.
Mezzanine: Family kitchen.
Second Floor: 1 large bedroom and 1 large bathroom.
Third Floor: 1 large bedroom, 1 storage room, and 1 bathroom.
Fourth Floor: 1 large bedroom, 1 walk-in closet, and 1 bathroom.
Fifth Floor: 1 large bedroom, 1 walk-in closet, and 1 bathroom.
Sixth Floor: 1 worship room and 1 laundry area.

This drawing includes the following plans: floor plan, elevation, and section of the building.
Feel free to view and download the entire CAD file of this townhouse for reference.
Additionally, you can download more house design drawings here

File format: .DWG
Size: 833 KB
Source: Collect
AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
