41.Transformer 300kVa Installation AutoCAD Blocks

41.Transformer 300kVa Installation AutoCAD Blocks
41.Transformer 300kVa Installation AutoCAD Blocks

41.Transformer 300kVa Installation AutoCAD Blocks

No. DESCRIPTION
1 CONCRETE POLE 12 M.
2 CROSSARM,CONCRETE SPUN 120x120x2000 mm.
3 CROSSARM,CONCRETE SPUN 100x100x2500 mm.
4 INSULATOR,SUSPENSION
5 INSULATOR,LINE POST
6 BRACE,FLAT 30x6x760 mm.
7 DROP OUT FUSE 100A
8 LIGHTNING ARRESTER
9 PARTIAL INSULATED CABLE 70 SAC.
10 WIRE STEEL STRANDED 25 mm.
11 OHGW BAYONET STEEL 65x65x6 mm. 2250mm. LONG
12 OHGW DEADEND STEEL 100x50x5 mm. 2250mm. LONG
13 GROUND ROD 60x60x5 mm. 2000mm. LONG.
14 TRANSFORMER 300 KVA 22KV/400-230V 3%%c 4w OIL TYPE
15 CROSSARM,CONCRETE SPUN 100x100x4500 mm.
16 BEAM CONCRETE 150x250x4600 mm.
17 STUB 300×5000 mm.

I also suggest downloading Electric Symbols.

  • File format: .DWG
  • Size: 216KB
  • Source: dwgshare.com
  • AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
