100. Download the design drawing of a 2‑story office building with an area of 250m2
This set of CAD drawings fully illustrates the architectural, structural, electrical, and plumbing components of a residential or small office building. The architectural section includes site location plans, front and side elevations, and longitudinal sections showing interior spaces and room layouts. The structural drawings detail foundations, columns, floor beams, roof beams, and reinforcement schedules to ensure durability and safety. The electrical and plumbing plans show ground and first floor power layouts, domestic water supply and drainage systems, roof drainage, and water tank details. Additional drawings include staircases, windows, doors, railings, and drainage pipe systems. All elements are clearly presented with dimensions, technical symbols, and annotations, providing essential support for both design and construction execution.
You may also consider downloading other Office building CAD drawings to support your project design
- File format: .DWG
- Size: 1.23 MB
- Source: DWGshare
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
