Change the interface of CAD high version to CAD 2007
The way to change the interface of CAD high version (ribbon) to CAD 2007 (classic)
(change the interface of CAD 201x to CAD 2007)
Hello everyone,
Today, we will introduce you to change the interface of AutoCAD high versions to the familiar interface of AutoCAD 2007.
From AutoCAD 2009 version forward, AutoCAD has Ribbon interface. From 2009 to 2014, users can come back to the classic interface by WSCURRENT command, then enter AutoCAD Classic. From version 2015 forward, you cannot come back to AutoCAD Classic version as previous versions. So how to change the interface of AutoCAD 2015 version forward to AutoCAD Classic, please follow our instruction!
The way to change:
Step 1: Enter MENUBAR, type 1 (Purpose is to display menu). Menu as the below picture:
Step 2: Enter RIBBONCLOSE (Purpose is to hide ribbon). It is the range with lots of unfamiliar things as below picture:
Step 3: Next, you click at Tools as below picture:
Next, you choose Toolbars/AutoCAD/. Finally, you choose the toolbars you want.
Small suggestion: There are 4 main toolbars to take out. They are Dimension; layers; properties and style.
Good luck!
Thanks for reading!!!
