3DF command – 3Dface command – Create 3D face

3DF command – 3Dface command – Create 3D face

1. The way to call 3DF command in AutoCAD.

Screen menu Type command
Draw2 » Surfaces » 3D face 3Dface, 3F

3Dface command creates a face including 3 or 4 edges in 3D space. You can enter the different Z coordinates for each vertex of this 3D face. Each face created by 3Dface command is a single object which is not exploded by Explode command.

  • 3Dface

Specify first point or [Invisible]: Select the first point or enter i option.

2. The options with 3DF command

  • First Point

This option defines the start point for 3Dface. After entering the start point, next you enter the rest points following to clockwise or counter-clockwise to create normal 3D face. If you fix all 4 points on the same plane, a planar face is created similarly as region object. When you shade the object by shade or render command, planar faces are shaded.

The invisible property comes before any order of catching point, separating point or entering the coordinates for that edge. You can create 3D face where all edges are invisible.

For example phantom, it does not appear at wireframe performance but it can be shaded.

3DF command – 3Dface command – Create 3D face

Picture 4.1 – 3Dface, create face
Picture 4.1 – 3Dface, create face
  • 3Dface

Specify first point or [Invisible]: – Enter the first point (P1),
Specify second point or [Invisible]: – Enter the second point (P2)
Specify third point or [Invisible] <exit>: – Enter the third point (P3)
Specify fourth point or [Invisible] <create three-sided face>: – Enter the fourth point (P4) or press Enter to create the face with 3 edges.
Specify third point or [Invisible] <exit>: – Enter the third point (P5) to create next face (take the last P3P4 of previous face as the start edge)
Specify fourth point or [Invisible] <create three-sided face>: – Enter the fourth point (P6)
Specify third point or [Invisible] <exit>: – Enter the next point or press Enter to complete (picture 4.1) including 2 faces: Face P1P2P3P4 and P3P4P5P6 with same edge P3P4.

Good luck!

Thanks for reading!!!
