344. Free Download of Mechanical and Electrical Construction Design Drawings for a 2-Story House
This set of 2-story house electrical system drawings provides a complete package of detailed construction documents for residential projects. It includes the drawing index, general notes, electrical symbols, single-line diagrams of main distribution boards for each floor, and detailed lighting layouts. The drawings clearly illustrate the placement of lighting fixtures, sockets, switches, and electrical devices, along with the overall distribution system to ensure accurate installation and construction. In addition, the documents cover important aspects such as power supply, lighting, internet, camera, and lightning protection systems, ensuring both safety and convenience for the building. This resource is highly useful for architects, electrical engineers, and construction students who need reliable reference materials for designing and implementing residential electrical systems. With clear presentation and practical details, the drawings make the design process more efficient and the construction process more accurate.
See more free sample electrical and plumbing drawings in this category
You can also find a wider selection of free Cad Blocks and DWG models available for download here: Free CAD Blocks download
- File format: .PDF
- Size: 8.10 MB
- Source: Bac Nguyen
- AutoCAD platform 2018 and later versions. For downloading files there is no need to go through the registration process
If you find our work useful, your support would mean a lot and help us grow even better.DONATE
